Key Features
- Product Thickness:5+5, 6+6, 8+8, 10+10, 12+12 double-layer laminated wired glass
(Available wire options: galvanized iron mesh, copper wire, stainless steel wire; wire diameter 0.1–0.3 mm) - Core Process:Flat glass is heated to a softening state (600–650°C) → metal wire embedded → slow annealing (to eliminate internal stress) → cutting and shaping → optional lamination (for enhanced safety).
- Safety Standards:Fire resistance complies with GB/T 15763.1-2009 – Safety Glass for Buildings, Part 1: Fire-Resistant Glass (Class C standard); impact resistance ≥50 kJ/㎡.
- Basic Properties:Light transmittance ≥75% (after wire embedding); heat resistance ≥400°C; after breakage, the wire mesh holds fragments together, preventing large pieces from falling.
Technical Advantages
- Fire Resistance:The embedded metal wire maintains structural integrity under high temperatures. Even when the glass softens or breaks in a fire, the wire mesh supports the fragments and delays the spread of flames and hot gases, providing crucial time for evacuation and firefighting — ideal for architectural fire safety applications.
- Anti-Theft Security:The composite structure of “glass + interlayer + metal wire” significantly enhances resistance to impact and cutting. It is difficult to penetrate with common tools, effectively deterring break-ins — suitable for ground-floor and street-facing areas.
- Deformation Resistance:The metal wire strengthens the overall rigidity of the glass, improving bending and wind-pressure resistance compared to standard laminated glass. It remains flat and stable over long-term use, ideal for large-area curtain walls and skylights.
- Distinct Aesthetic Appeal:The metal wire forms unique textures (e.g., diamond mesh, linear patterns) that can be paired with clear or frosted glass to create industrial or vintage interior styles, combining safety with design aesthetics. Custom patterns are available.
Application Scenarios
Fire-Protection Areas:Building fire partitions, fire-rated doors, elevator shaft glass.
Security Zones:Street-facing shop windows, villa ground-floor windows, warehouse partitions.
- Decorative Spaces:Bars, restaurant walls, industrial-style office dividers, glass screens.
